- The ground feeler is equipped with a collar 1 mm diameter for measuring tubes still have a burr from parting
- Ground feeler pin of 6 mm diameter
- USB Data Output (requires optional cable, DCPRMD-USB)
- Opening by lifting device (lever) - self closing thickness gauge
| Resolution | 0.01 mm / 0.0005 inch |
| Measuring range | 0 - 10 mm / 0.4 inch |
| Depth of Jaw | 50 mm |
| Measuring principle | Self closing |
| Display | LCD 6 digit, 8.5 mm high |
| Measuring system | Capazitiv (Sylvac) |
| Temperature range | 10 - 45 °C |
| Battery | 3 V Lithium, CR 2032 |
| Data output | RS 232, galvanic isolation |
| Weight, net (gross) | 300 g (350 g) |
| Item | Description | Price | ||
|---|---|---|---|---|
Tube Wall Thickness Gauge | $745.00 | |||
| Accessories | ||||
DCPRMD-USB | USB Data Output Cable (2m/6ft) for FD and JD thickness Gauges with Free Software | $195.00 | ||
In stock
1 Week Lead Time (Estimated)
2-3 Week Lead Time (Estimated)
Lead Time Varies, Please contact us for availability.
Unavailable
